ELITE Ti² Fishfinder/Chartplotter touchscreen (Widescreen, 16:9 colour TFT LCD display, with LED backlighting), high sensitivity internal antenna, NMEA 2000 interface. The new Elite Ti² series is equipped with complete wireless connectivity, offering the possibility of sharing sonar images and nautical charts between two Elite Ti² displays in wireless way, as well as synchronizing the waypoint data. For maximum practicality in the water it is also possible to visualize via Bluetooth® the incoming SMS / phone calls notifications directly on the Elite Ti² screen, allowing you to keep your smartphone in a safe place. Thanks to the new Active Imaging ™ sonar, the bottom can be probed more quickly with a level of detail and image quality leader in the sector, with covers never reached before by other technologies. Supplied with HDI Med / High 83/200 and DownScan 455/800 kHz transducer or with new Active Imaging ™ 3-IN-1 transducer, quick release adjustable swivel mounting bracket, power cable, protective cover, Italian and multilingual software.
Compatibility with VHF and auto-pilot.
Depth up to
90 m approx* (DownScan 455/800 kHz).
300 m approx* (with 83/200 kHz transducer).
450 m approx* (with 50/200 kHz transducer).
750 m approx* (with 1 kW traditional transducer).
* depth capacity depends on sea bottom and other water conditions.
Optional Navionics+ – Platinum+ – C-MAP Max-N and N+ SD cartography.
Code | Description |
---|---|
GN622881 822.97 € + ddv | ELITE-7 Ti² Fishfinder/Chartplotter (7″ display – 800×480 pixel) with transom mount transducer with depth/temp. HDI Mid/High CHIRP 83/200 and DownScan 455/800 kHz |
GN622882 925.97 € + ddv | ELITE-7 Ti² Fishfinder/Chartplotter (7″ display – 800×480 pixel) with transom mount transducer with depth/temp. Active Imaging™ 3-IN-1 (Mid/High CHIRP 83/200, DownScan and SideScan 455/800 kHz) |
GN622881/S 771.47 € + ddv | ELITE-7 Ti² Fishfinder/Chartplotter (7″ display – 800×480 pixel) without transducer |
GN622865 1,286.47 € + ddv | ELITE-9 Ti² Fishfinder/Chartplotter (9″ display – 800×480 pixel) with transom mount transducer with depth/temp. Active Imaging™ 3-IN-1 (Mid/High CHIRP 83/200, DownScan and SideScan 455/800 kHz) |
GN622865/S 1,183.47 € + ddv | ELITE-9 Ti² Fishfinder/Chartplotter (9″ display – 800×480 pixel) without transducer |
GN622870 2,367.97 € + ddv | ELITE-12 Ti² Fishfinder/Chartplotter (12″ display – 1280×800 pixel) with transom mount transducer with depth/temp. Active Imaging™ 3-IN-1 (Mid/High CHIRP 83/200, DownScan and SideScan 455/800 kHz) |
GN622870/S 2,264.97 € + ddv | ELITE-12 Ti² Fishfinder/Chartplotter (12″ display – 1280×800 pixel) without transducer |
Spare parts | |
---|---|
GN623030 30.89 € + ddv | Power cable for ELITE – 7 – 9 – 12 Ti² |
GN623022 25.21 € + ddv | Mounting bracket for ELITE-7 Ti² |
GN623028 46.42 € + ddv | Mounting bracket for ELITE-9 Ti² |
GN623029 58.03 € + ddv | Mounting bracket for ELITE-12 Ti² |
GN623018 22.25 € + ddv | Protective cover for ELITE-7 Ti² |
GN623019 30.26 € + ddv | Protective cover for ELITE-9 Ti² |
GN623020 30.26 € + ddv | Protective cover for ELITE-12 Ti² |
GN622974 338.77 € + ddv | Active Imaging™ 3-IN-1 transom mount transducer with depth/temp. (Mid/High CHIRP 83/200, DownScan and SideScan 455/800 kHz) supplied as standard on GN622882 / GN622865 / GN622870 |
GN622967 135.91 € + ddv | HDI Skimmer DownScan 83/200/455/800 kHz transom mount transducer (supplied as standard on GN622881) |
